An Arabic, calculator-driven technical proposal for a 25-branch Hikvision 8MP CCTV upgrade

This is an Arabic right-to-left technical and procurement proposal site for replacing a CCTV system with Hikvision 8MP equipment across 25 branches of Nayifat. It opens on an executive summary with headline counters for 351 cameras, 26 recorders, 238 sixteen-terabyte drives and about 3.14 petabytes of 180-day recording, then presents the calculation assumptions, the approved model list, an editable per-branch storage table, a branch distribution table, a full bill of materials, a license breakdown, an explanation of the Riyadh control center, single-line diagrams, a branch-by-branch execution plan and a complete RFQ workspace. A separate prequalification page gathers mandatory vendor documents and evaluation criteria, and a datasheet library links to a specification page for each approved model. Everything can be exported to PDF or Word, or printed section by section.

Highlights

Live storage math

Drives recalc live

BOM and licenses

Quantities and codes

Branch, center flows

Diagrams included

Editable RFQ

Prices and margin

PDF and Word export

Print per section

How to Use

Open the summary
Load the homepage and read the executive summary block at the top, which shows the headline counts for cameras, recorders, drives, total storage and licenses, followed by the assumptions used for the storage math and the short answer about central storage at the Riyadh center.
Review models and numbers
Use the top anchor navigation to move between the approved models table, the storage table, the branch distribution table, the BOM, the licenses section and the diagrams. Model names inside the tables link to their individual datasheet pages, and a separate link opens the full datasheet library.
Adjust branch inputs
In the storage table each branch row has a camera-count field. Change a value and that row recalculates its net terabytes and its number of 16TB RAID 5 drives immediately, and the table totals update as well. This lets you test how different camera counts affect storage and drive quantities.
Prepare the quote and export
Scroll to the RFQ section to read the scope of work, vendor instructions, editable price table with vendor prices and profit margin, commercial terms, mandatory technical requirements, delivery milestones and the document checklist. Then use the section checkboxes plus the PDF or Word export buttons, or the per-section print buttons, to produce the output you need.
